Steel Slab Lifting Clamp Billet Lifting Clamp For Crane Hook

Release time：2024-04-24 07:41viewed：times

Steel Billet Lifting Clamp

Steel Billet Hanging Clamp

Steel Slab Lifting Clamp

Jiangsu Xingsheng Lifting Equipment Co., Ltd manufacture Steel Billet Lifting Clamp Crane Hook,Steel Billet Clamp,Steel Billet Hanging Clamp,Steel Slab Lifting Clamp Billet Lifting Clamp For Crane.

Steel Slab Lifting Clamp, also known as the Billet Lifting Clamp, is a specialized tool designed for efficient and safe lifting of heavy steel slabs or billets using a crane or lifting equipment. This clamp is engineered to withstand the demands of rigorous material handling in industrial settings such as steel mills, foundries, and manufacturing plants.

Made from high-quality, high-strength materials, the lifting clamp is built to last and can handle the immense weight of steel slabs or billets without compromising its structural integrity. Its robust design ensures minimal risk of damage to the steel during the lifting process, which is crucial for maintaining the quality of the material.

Steel Slab Lifting Clamp Billet Lifting Clamp For Crane is designed with a tight-holding mechanism that securely grips the slabs or billets, providing a firm and stable hold during lifting and transport. This feature minimizes the risk of slippage or shifting, ensuring the safety of the operators and the integrity of the steel products.

Compatible with a variety of crane systems, the Steel Slab Lifting Clamp offers flexibility in material handling. It can be easily attached to the crane's lifting hook or attachment point, allowing for a quick and secure connection.

Steel Slab Lifting Clamp Billet Lifting Clamp For Crane is essential for operators who need to handle steel products that are in the form of slabs or billets. Its specialized design ensures that these materials can be lifted and transported safely, efficiently, and without damage, making it an indispensable tool in the steel industry and related sectors.

Steel Billet Lifting Clamp Crane Hook

Rated load (t)	Applied range(mm)	Billet smallest thickness(mm)	Span (mm)	Max dimension (mm)	Self weight (kg)	W
3	100-300	60	800	1200	1600	350
5	100-300	70	800	1200	1800	500
5	170-350	80	800	1300	1800	600
5	450-600	100	800	1200	1800	600
5	650-1000	140	800	1500	2300	850
8	150-450	90	1200	2000	2400	1300
8	450-600	110	1200	1600	2500	1300
8	450-750	130	1200	1600	2200	1350
10	450-900	140	1500	1900	2600	2200
10	650-1000	150	1500	1600	2600	1800
10	700-1100	160	1500	1700	2600	1900
12	450-750	120	2000	1800	2400	2600
12	235-800	150	2000	2300	3000	2700
16	450-750	120	2500	2000	2700	3600
16	450-900	140	2500	2100	3000	3800
16	650-1000	150	2500	2000	2700	3800
16	600-1100	190	2500	2400	3100	4200
16	850-1250	160	2500	2000	3000	4200
20	700-1100	150	3000	2200	3200	4600
20	800-1300	170	3000	2200	3400	4800
20	950-1400	160	3000	2500	3500	4800
